Conical Reducer, ISO-K
Universal conical reducer, ISO-K for vacuum systems. PRECESS provides various kinds of flange for pipeline connection of your system.
Home > Products > Conical Reducer > Conical Reducer, ISO-K
Conical Reducer, ISO-K

We fabricate these KF (QF) nipples (spools) for HV systems from tubing and KF flanges. The KF (QF) flange is used for through- or foreline vacuum plumbing and for simple HV chamber ports.

Key features of the Conical Reducer, ISO-K
Features:
Half nipples feature one KF flange
Full nipples feature two KF flanges
Benefits:
Conical and straight reducer nipples adapt two different flange sizes
Common lengths and tube diameters listed; contact us with your specific requirements
TECHNICAL DATA
Downloads
SIZES
 DN16 to 100mm
Flange
ISO-K
MATERIAL
SS / Aluminum
LEAK RATE
< 1 × 10-9 mbar l/s
PRESSURE RANGE
 1 × 10-9 mbar to 2 bar (abs)

Conical Reducer, ISO-K
612.07KB PDF
Download
SPECIFY STANDARD PRODUCT
Get to the product details to specify your requirements to get a quote or to get a specific CAD data download.
Part No.
Size
Description
φA
φB
L
L
Manual
Price
Stock

CCRK6380
ISOK63,80
Conical Reducer, ISO-K
95
110
81
67
CCRK63100
ISOK63,100
Conical Reducer, ISO-K
95
130
117
103
CCRK63160
ISOK63,160
Conical Reducer, ISO-K
95
180
153.7
139.7
CCRK80100
ISOK80,100
Conical Reducer, ISO-K
110
130
117
103
CCRK80160
ISOK80,160
110 180 153.7 139.7
110
180
153.7
139.7
CCRK100160
ISOK100,160
Conical Reducer, ISO-K
130
180
153.7
139.7
CUSTOMIZED SOLUTION
Specify your customized solution.
If you have your specification already at hand, please upload it and submit it to us. We are happy to send you a quote.
Upload your specification
Maximum upload size: 15 MB, only JPG, PNG, CAD, PDF files are acceptable.
