Elbow, ISO-F(90 degree)
Universal elbow, ISO-F(90 degree) for vacuum systems. PRECESS provides various kinds of flange for pipeline connection of your system.
Home > Products > Elbow > Elbow, ISO-F(90 degree)
Elbow, ISO-F(90 degree)

We fabricate these ISO-F elbows for HV systems from tubing and KF flanges. The ISO-F flange is used for through- or foreline vacuum plumbing and for simple HV chamber ports.

Key features of the Elbow, ISO-F(90 degree)
Features:
Available in 316L stainless steel or aluminum 6061-T6 (miter elbows only)
Radius or miter design
Benefits:
Common lengths and tube diameters listed; contact us with your specific requirements
TECHNICAL DATA
Downloads
SIZES
 DN63 to 250mm
Flange
 ISO-F
MATERIAL
 SS / Aluminum
LEAK RATE
 < 1 × 10-9 mbar l/s
PRESSURE RANGE
1 × 10-9 mbar to 2 bar (abs)

Elbow, ISO-F(90 degree)
680.63KB PDF
Download
SPECIFY STANDARD PRODUCT
Get to the product details to specify your requirements to get a quote or to get a specific CAD data download.
Part No.
Size
Description
φA
φB
D
d
Manual
Price
Stock

DEL13HF
CF1.33[2H-2F]
Elbow, ISO-F(90 degree)
34
19.05
28.5
4.3
DEL13HR
CF1.33[2H-2R]
Elbow, ISO-F(90 degree)
34
19.05
28.5
4.3
DEL13HRX
CF1.33[2H-1R]
Elbow, ISO-F(90 degree)
34
19.05
28.5
4.3
DEL13TF
CF1.33[2T-2F]
Elbow, ISO-F(90 degree)
34
19.05
28.5
4.3
DEL13TR
CF1.33[2T-2R]
Elbow, ISO-F(90 degree)
34
19.05
28.5
4.3
DEL13TRX
CF1.33[2T-1R]
Elbow, ISO-F(90 degree)
34
19.05
28.5
4.3
DEL13TRZ
CF1.33[1T-1H-1R]
Elbow, ISO-F(90 degree)
34
19.05
28.5
4.3
DEL21HF
CF2.125[2H-2F]
Elbow, ISO-F(90 degree)
53.8
25.4
35
8.9
DEL21HR
CF2.125[2H-2R]
Elbow, ISO-F(90 degree)
53.8
25.4
35
5.9
DEL21HRX
CF2.125[2H-1R]
Elbow, ISO-F(90 degree)
53.8
25.4
35
8.9
DEL21TF
CF2.125[2T-2F]
Elbow, ISO-F(90 degree)
53.8
25.4
35
8.9
DEL21TR
CF2.125[2T-2R]
Elbow, ISO-F(90 degree)
53.8
25.4
35
5.9
DEL21TRX
CF2.125[2T-1R]
Elbow, ISO-F(90 degree)
53.8
25.4
35
8.9
DEL21TRZ
CF2.125[1T-1H-1R]
Elbow, ISO-F(90 degree)
53.8
25.4
35
8.9
DEL27HF
CF2.75[2H-2F]
Elbow, ISO-F(90 degree)
69.5
38.1
50
5.7
DEL27HR
CF2.75[2H-2R]
Elbow, ISO-F(90 degree)
69.5
38.1
50
5.7
DEL27HRX
CF2.75[2H-1R]
Elbow, ISO-F(90 degree)
69.5
38.1
50
5.7
DEL27TF
CF2.75[2T-2F]
Elbow, ISO-F(90 degree)
69.5
38.1
50
5.7
DEL27TR
CF2.75[2T-2R]
Elbow, ISO-F(90 degree)
69.5
38.1
50
5.7
DEL27TRX
CF2.75[2T-1R]
Elbow, ISO-F(90 degree)
69.5
38.1
50
5.7
DEL27TRZ
CF2.75[1T-1H-1R]
Elbow, ISO-F(90 degree)
69.5
38.1
50
5.7
DEL33HF
CF3.375[2H-2F]
Elbow, ISO-F(90 degree)
86
50.8
60
8
DEL33HR
CF3.375[2H-2R]
Elbow, ISO-F(90 degree)
86
50.8
60
7.5
DEL33HRX
CF3.375[2H-1R]
Elbow, ISO-F(90 degree)
86
50.8
60
8
DEL33TF
CF3.375[2T-2F]
Elbow, ISO-F(90 degree)
86
50.8
60
8
DEL33TR
CF3.375[2T-2R]
Elbow, ISO-F(90 degree)
86
50.8
60
7.5
DEL33TRX
CF3.375[2T-1R]
Elbow, ISO-F(90 degree)
86
50.8
60
8
DEL33TRZ
CF3.375[1T-1H-1R]
Elbow, ISO-F(90 degree)
86
50.8
60
8
DEL45HF
CF4.5[2H-2F]
Elbow, ISO-F(90 degree)
113.5
63.5
79
9.5
DEL45HR
CF4.5[2H-2R]
Elbow, ISO-F(90 degree)
113.5
63.5
79
10.7
DEL45HRX
CF4.5[2H-1R]
Elbow, ISO-F(90 degree)
113.5
63.5
79
9.5
DEL45TF
CF4.5[2T-2F]
Elbow, ISO-F(90 degree)
113.5
63.5
79
9.5
DEL45TR
CF4.5[2T-2R]
Elbow, ISO-F(90 degree)
113.5
63.5
79
10.7
DEL45TRX
CF4.5[2T-1R]
Elbow, ISO-F(90 degree)
113.5
63.5
79
9.5
DEL45TRZ
CF4.5[1T-1H-1R]
Elbow, ISO-F(90 degree)
113.5
63.5
79
9.5
DEL06HF
CF6[2H-2F]
Elbow, ISO-F(90 degree)
152
101.6
130
10
DEL06HR
CF6[2H-2R]
Elbow, ISO-F(90 degree)
152
101.6
130
11.3
DEL06HRX
CF6[2H-1R]
Elbow, ISO-F(90 degree)
152
101.6
130
10
DEL06TF
CF6[2T-2F]
Elbow, ISO-F(90 degree)
152
101.6
130
10
DEL06TR
CF6[2T-2R]
Elbow, ISO-F(90 degree)
152
101.6
130
11.3
DEL06TRX
CF6[2T-1R]
Elbow, ISO-F(90 degree)
152
101.6
130
10
DEL06TRZ
CF6[1T-1H-1R]
Elbow, ISO-F(90 degree)
152
101.6
130
10
