Full Nipple, ISO-KF
Universal full nipple, ISO-KF for vacuum systems. PRECESS provides various kinds of flange for pipeline connection of your system.
Home > Products > Full Nipple > Full Nipple, ISO-KF
Full Nipple, ISO-KF
We fabricate these KF (QF) nipples (spools) for HV systems from tubing and KF flanges. The KF (QF) flange is used for through- or foreline vacuum plumbing and for simple HV chamber ports.
Key features of the Full Nipple, ISO-KF
Features:
Low cost of ownership
Half nipples feature one KF flange
Full nipples feature two KF flanges
Benefits:
Conical and straight reducer nipples adapt two different flange sizes
Common lengths and tube diameters listed; contact us with your specific requirements
TECHNICAL DATA
Downloads
SIZES
DN16 to 50mm
Flange
 ISO-KF
MATERIAL
 SS / Aluminum
LEAK RATE
 < 1 × 10-9 mbar l/s
PRESSURE RANGE
 1 × 10-9 mbar to 2 bar (abs)

Full Nipple, ISO-KF
559.8KB PDF
Download
SPECIFY STANDARD PRODUCT
Get to the product details to specify your requirements to get a quote or to get a specific CAD data download.
Part No.
Size
Description
φA
φB
L
Manual
Price
Stock

CFUN16
NW16
Full Nipple, ISO-KF
30
19.05
100
CFUN25
NW25
Full Nipple, ISO-KF
40
25.4
100
CFUN40
NW40
Full Nipple, ISO-KF
55
38.1
100
CFUN50
NW50
Full Nipple, ISO-KF
75
50.8
100
CUSTOMIZED SOLUTION
Specify your customized solution.
If you have your specification already at hand, please upload it and submit it to us. We are happy to send you a quote.
Upload your specification
Maximum upload size: 15 MB, only JPG, PNG, CAD, PDF files are acceptable.
